Support / Gretsch Wiring Diagrams & Fitting Instructions
Please find a list below of Gretsch wiring diagrams and fitting instructions for our Gretsch wiring harnesses which include popular Gretsch guitar models. These Gretsch guitar wiring diagrams are listed for our customers and anyone taking on a wiring project on their guitar. These wiring diagrams are completely free to use, however they are not to be sold as they are the property of AxeKool Guitars.
If you like and use our FREE Gretsch wiring diagrams and would like to show your appreciation, please buy our team a coffee, thank you.
Gretsch Models
Gretsch Hollowbody Wiring Diagram
2 x Filter’Tron, Master Volume, 2 x Volume, Tone and 3 Way Toggle Switch.
Gretsch Solid Body Wiring Diagram
2 x Filter’Tron, Master Volume, 2 x Volume, Tone and 3 Way Toggle Switch.
Gretsch Billy Bo Wiring Diagram
2 x Filter’Tron, Master Volume, 2 x Volume, Tone and 3 Way Toggle Switch.
————
