Pre-Wired Switchcraft Mustang/Duosonic 3 Position Slide Switches x 2
£23.95
Pre-Wired Switchcraft Mustang/Duosonic 3 Position Slide Switches x 2
Shipping calculated at checkout
- Quality Product.
- Contact us with any questions you have about this item.
Description
Pre-Wired Switchcraft Mustang/Duosonic 3 Position Slide Switches x 2
We use Switchcraft Switches as standard on our Mustang Wiring Harnesses, simply because they are one of the best. By investing in a high quality switch you will get many more hours of use due to the durability of the product.
This three-position switch can be wired as on/on/on or on/off/on.
Components
- Switchcraft USA 3 Position Slide Switches x 2, Black or White Switch Tips Available.
- Gavitt Vintage 22 Gauge Cloth Covered Wire, Cream.
- Gavitt Vintage 22 Gauge Cloth Covered Wire, Black.
- Tinned Copper “Buss” Ground Wire.
- Mounting screws included.
- Heatshrink Insulation Sleeving.
- Mounted on a 3D Printed Wiring Template.
Measurements:
- 35mm centre to centre of the two mounting screw holes.
Specifications:
- Contact Ratings: Fine silver contacts rated at 3A, 300W maximum AC non-inductive load standard.
- Leakage Resistance: 1,000 MW or greater.
- Dielectric Strength: 250 VDC.
- Frame: Steel, plated.
- Knob: Black moulded thermoplastic.
The Pre-Wired Switchcraft Mustang/Duosonic 3 Position Slide Switches x 2 are wired in the traditional vintage Mustang style, Please see our Support pages for wiring diagrams.
Order Times
We make everything to order and the turnaround time for a Pre-Wired Switchcraft Mustang/Duosonic 3 Position Slide Switches x 2 is 48 hours.
