Please find a list below of Left Handed Ibanez Wiring Diagrams and Fitting Instructions for our Left Handed Ibanez Wiring Harnesses which include popular Left Handed Ibanez guitar models. These Left Handed Ibanez guitar wiring diagrams are listed for our customers and anyone taking on a wiring project on their guitar. These Left Handed Ibanez Wiring Diagrams are completely free to use, however they are not to be sold as they are the property of AxeKool Guitars.
If you like and use our FREE Left Handed Ibanez Wiring Diagrams and would like to show your appreciation, please buy our team a coffee, thank you.
Ibanez Left Handed Models
Ibanez Hollowbody Left Handed Wiring Diagram
2 x Humbuckers / P90’s, 2 x Volume Pots, 2 x Tone Pots, 3 Way Toggle Switch.
Ibanez HSH Left Handed Wiring Diagram
2 x Humbucker Pickups, 1 x Single Coil Pickup (middle), Volume Pot, Tone Pot, 5 Way Blade Switch.
Ibanez HSH Coil Split Left Handed Wiring Diagram
2 x Humbucker Pickups, 1 x Single Coil Pickup (middle), Volume Pot, Tone Pot, 5 Way Blade Switch.
Ibanez HSH RG & Jem Left Handed Wiring Diagram
2 x Humbucker Pickups, 1 x Single Coil Pickup (middle), Volume Pot, Tone Pot, 5 Way Blade Switch.
Ibanez HSH RG & Jem Coil Split Left Handed Wiring Diagram
2 x Humbucker Pickups, 1 x Single Coil Pickup (middle), Volume Pot, Tone Pot, 5 Way Blade Switch.
Ibanez HH Left Handed Wiring Diagram
2 x Humbucker Pickups, Volume Pot, Tone Pot, 3 Way Blade Switch.
Ibanez HH Series / Parallel Left Handed Wiring Harness
2 x Humbucker Pickups, Volume Pot, Tone Pot, 5 Way Blade Switch.
———————
